Summery

FDP75N08A is a high quality transistor. Submit an inquiry to buy this transistor directly from China, with no intermediary at the cheapest price and valid warranty.

CategoryTransistor
BrandCHINA-MARKET
Datasheet DataSheet

Quantity

+
-

FDP75N08A Attributes

  • Mounting Style Through Hole
  • Package / Case TO-220-3
  • Vds - Drain-Source Breakdown Voltage 75 V
  • Id - Continuous Drain Current 75 A
  • Rds On - Drain-Source Resistance 11 mOhms
  • Vgs - Gate-Source Voltage -20 to +20 V
  • Vgs th - Gate-Source Threshold Voltage 2 V
  • Qg - Gate Charge 104 nC
  • Minimum Operating Temperature -55 C
  • Maximum Operating Temperature +150 C
  • Pd - Power Dissipation 137 W
  • Series FDP75N08A
  • Fall Time 147 ns
  • Height 16.3 mm
  • Length 10.67 mm
  • Rise Time 212 ns
  • Factory Pack Quantity 50
  • Typical Turn-Off Delay Time 273 ns
  • Typical Turn-On Delay Time 43 ns
  • Width 4.7 mm
