FDP39N20

FDP39N20

FDP39N20

5 of 5

Summery

FDP39N20 is a high quality transistor. Submit an inquiry to buy this transistor directly from China, with no intermediary at the cheapest price and valid warranty.

CategoryTransistor
BrandCHINA-MARKET
Datasheet DataSheet

Quantity

+
-

FDP39N20 Attributes

  • Package / Case TO-220-3
  • Mounting Style Through Hole
  • Vds - Drain-Source Breakdown Voltage 200 V
  • Id - Continuous Drain Current 39 A
  • Rds On - Drain-Source Resistance 66 mOhms
  • Vgs - Gate-Source Voltage -30 to +30 V
  • Vgs th - Gate-Source Threshold Voltage 3 V
  • Qg - Gate Charge 49 nC
  • Minimum Operating Temperature -55 C
  • Maximum Operating Temperature + 150 C
  • Pd - Power Dissipation 251 W
  • Series FDP39N20
  • Fall Time 150 ns
  • Forward Transconductance - Min 28.5 S
  • Height 16.3 mm
  • Length 10.67 mm
  • Rise Time 160 ns
  • Factory Pack Quantity 1000
  • Typical Turn-Off Delay Time 150 ns
  • Typical Turn-On Delay Time 30 ns
  • Width 4.7 mm
  • Unit Weight: 0.068784 oz
