Summery

IRFP31N50LPB is a high quality transistor. Submit an inquiry to buy this transistor directly from China, with no intermediary at the cheapest price and valid warranty.

CategoryTransistor
BrandCHINA-MARKET
Datasheet DataSheet

Quantity

+
-

IRFP31N50LPB Attributes

  • Mounting Style Through Hole
  • Package / Case TO-247AC-3
  • Vds - Drain-Source Breakdown Voltage 500 V
  • Id - Continuous Drain Current 31 A
  • Rds On - Drain-Source Resistance 180 mOhms
  • Vgs - Gate-Source Voltage -30 to +30 V
  • Vgs th - Gate-Source Threshold Voltage 3 V
  • Qg - Gate Charge 210 nC
  • Minimum Operating Temperature -55 C
  • Maximum Operating Temperature +150 C
  • Pd - Power Dissipation 460 W
  • Fall Time 53 ns
  • Forward Transconductance - Min 15 S
  • Height 20.82 mm
  • Length 15.87 mm
  • Factory Pack Quantity 500
  • Typical Turn-Off Delay Time 54 ns
  • Typical Turn-On Delay Time 28 ns
  • Width 5.31 mm
